Rotary Tray Weight Grader - Small Tray

Equipment features:

 1. High-precision load cell and automatic zero tracking system ensure accurate and reliable weighing data.

 2. Lekon grader can store a variety of product data, suitable for various items that need to be sorted by weight.

 3. Factory parameter setting recovery function, user can set multi-stage weight calibration.

 4. Frequency conversion control, easy to adjust speed, batching, counting can be supplied.

 5. HMI touchscreen to manage the process, intuitive display, user friendly, accurate performance.

 6. Robust fully stainless steel 304/316L wash-down construction, easy to clean, easy to move.

Inquire now
Add to inquiry car
Rotary Tray Weight Grader - Small Tray
Rotary Tray Weight Grader - Small Tray
Rotary Tray Weight Grader - Small Tray
Rotary Tray Weight Grader - Small Tray
Rotary Tray Weight Grader - Small Tray
Rotary Tray Weight Grader - Small Tray
Rotary Tray Weight Grader - Small Tray
Rotary Tray Weight Grader - Small Tray

Product Details

Rotary graders are specialized machines used primarily in food processing and packaging industries to automate the sorting and grading of products based on their weight. Based on pre-set parameters, products are classified into different weight categories. This can involve diverting products into different chutes or conveyor belts based on their weight.

Equipment features

  • Rotary Tray Weight Grader - Small Tray 1

  • Rotary tray weight grader- small tray detail

  • Rotary tray weight grader- small tray detail 1

Applications

  • Seafood

    Seafood

  • Chicken by-products

    Chicken by-products

  • shellfish

    shellfish

  • Fish fillets

    Fish fillets

Specifications


Model

Grading speed (times/min)

Accuracy (g)

Weight range (g)

Overall dimensions (mm)

Power (W)

Power Supply (V/Hz)

WFH-05S

320-420

0.1

5-500

3200×1000×1470

200 W

AC220/50

(customized)

WFH-06S

320-420

0.1

5-500

3600×1000×1500

WFH-08S

320-420

0.1

5-500

4600×1000×1500

WFH-10S

320-420

0.1

5-500

5200×1000×1470

400 W

WFH-12S

320-420

0.1

5-500

6600×1000×1470
